客户名称：山西朔州第二垃圾填埋场
水质类型：填埋场渗滤液
膜型号：SP-DTRO3-8042（75bar）
数量：55支（一级45支，二级10支）
处理量：100m³/d
投运时间：2021年4月
DTRO运行参数：
一级进/产水流量：5/4m³/h
二级产水流量：3.1m³/h
一级/二级进膜：57.9/23.8bar
原液/一级浓缩液/一级产水/二级产水电导：28.6/51.8/0.839/0.0723ms/cm
Water quality type: Landfill leachate
Membrane model: SP-DTRO5-8042
Quantity: 120 (96 for the first grade, 24 for the second grade)
Capacity: 250m³/d
Put into operation: May 2021
DTRO operating parameters:
First stage inlet/outlet pressure: 52.4/46bar;
Secondary inlet/outlet pressure: 18/17.4 bar
Primary/secondary water flow rate 7.8/6m³/h;
Raw water/primary/secondary water conductance: 26320/1240/188.7μs/cm
Water quality type: Landfill leachate
Membrane type: SP-DTRO5-8042/SP-DTRO3-8042
Quantity: 44 (36 for Level 1, 8 for Level 2)
Capacity: 80m³/d
Put into operation: October 2021
DTRO operating parameters:
First stage inlet/outlet pressure: 36/26bar;
Primary/secondary permeate flow rate 3.5/2.3m³/h;
Raw water/primary/secondary water conductance: 18300/123/85μs/cm
Water quality type: Landfill leachate
Membrane model: SP-DTRO3-8042 (75bar)
Quantity: 55 (45 for the first grade, 10 for the second grade)
Capacity: 100m³/d
Put into operation: April 2021
DTRO operating parameters:
Primary inlet/permeate flow: 5/4m³/h
Secondary water flow: 3.1 m³/h
Primary/secondary inlet: 57.9/23.8 bar
Stock solution/primary concentrate/primary produced water/secondary produced water conductance: 28.6/51.8/0.839/0.0723ms/cm
Water quality type: Landfill leachate
Membrane type: SP-DTRO5-8042 (90bar)
Quantity: 36 (diaphragm replacement)
Capacity: 120m³/d
Put into operation: June 2024
Running parameters:
Inlet/permeate flow: 6.4/4.6 m³/h
Inlet pressure: 32-40 bar
Influent/Produced Water Conductance: 14780/297μs/cm (Normal)
Concentrate conductance: 35600ms/cm
Water quality type: incineration site leachate
Membrane model: SP-DTRO3-8042 (75bar)
Quantity: 74 pcs
Capacity: 200m³/d
Put into operation: March 2021
Running parameters:
Inlet/permeate flow: 10.5/7.7 m³/h
Film inlet pressure: 19.9-25.3 bar
Influent/Produced Water Conductance: 13500/460μs/cm (Normal)
Concentrate conductance: 24500ms/cm
Water quality type: glyphosate production wastewater
Membrane type: SP-DTRO5-8042 (90bar)
Quantity: 60 pieces (1st class)
Capacity: 150m³/d
Put into operation: March 2022
Running parameters:
Permeate/concentrate flow: 4.5/1.5m³/h
Inlet pressure: 20-68 bar
Influent/Produced Water Conductance: 7000-20000/400-600μs/cm (Normal)
Quantity: 80 pcs, 40 pcs/set
Capacity: 300m³/d
Put into operation: July 2022
Running parameters:
Inlet/permeate flow: 14.5/7.5 m³/h
Inlet pressure: 35-40 bar
Influent/water conductance: 30000/450μs/cm
