客户名称：信阳钢铁金港能源有限公司
水质类型：烟气脱硫冷凝废水
膜型号：SP-STRO5-8042（90bar）
数量：450支
处理量：162m³/h
投运时间：2023年4月
运行参数：
进水/产水流量：27/22m³/h
进膜压力：24-33bar
进水/产水电导：8000-10000/515μs/cm
pH：4.0-6.5
现场特点：氟离子，二氧化硅含量高，进水电导远低于设计值
Water quality type: incineration site leachate
Membrane model: SP-STRO3-8042 (75bar)
SP-DTRO5-8042（90bar）
Quantity: 60 pcs. &50 pcs
Capacity: 600m³/d
Put into operation: August 2021
STRO operating parameters:
Inlet/permeate flow: 9.6/7.7m³/h
Inlet/outlet pressure: 41/37.5 bar
Influent/produced water/concentrated water conductance: 21200/765/44982μs/cm
pH: 6.7, operating temperature: 32°C
Water quality type: flue gas desulfurization condensate wastewater
Membrane model: SP-STRO5-8042 (90bar)
Quantity: 450 pcs
Capacity: 162m³/h
Put into operation: April 2023
Running parameters:
Inlet/permeate flow: 27/22 m³/h
Film inlet pressure: 24-33 bar
Influent/Produced Water Conductance: 8000-10000/515μs/cm
pH：4.0-6.5
Site features: high content of fluoride ions, silica, and inlet water conductance is far below the design value.
Water quality type: coking integrated wastewater
Membrane model: SP-STRO3-8042 (75bar)
Quantity: 82 pcs
Capacity: 500m³/d
Put into operation: September 2022
Running parameters:
Inlet/permeate flow: 10/5.5m³/h
Inlet pressure: 35 bar
Influent/Produced Water Conductance: 16000/650μs/cm
Water quality type: coking integrated wastewater
Membrane model: SP-STRO5-8042 (90bar)
Quantity: 142 pieces (core replacement project)
Capacity: 750m³/d
Put into operation: May 2023
70pcs/set operating parameters:
Inlet/permeate flow: 32/17.5m³/h
Inlet/outlet pressure: 56.8/58.9/59.5/55.2 bar
Inlet water conductance: 60-78.5ms/cm
Conductance: 1200-1945μs/cm
Concentrate conductance: 109-140ms/cm
Water quality type: coking integrated wastewater
Membrane model: SP-STRO5-8042 (75bar)
Quantity: 298 pieces (core replacement project)
Capacity: 2500m³/d
Put into operation: January 2024
96 pcs/set operating parameters:
Inlet/permeate flow: 55/44 m³/h
Inlet pressure: 37-43 bar
Inlet water conductance: 12-19ms/cm
Conductance of water production: 300-500μs/cm
Concentrate conductivity: 57-80ms/cm
Water quality type: coking integrated wastewater
Membrane type: SP-STRO-8042 (75bar)
Quantity: 96 pieces (core replacement project)
Capacity: 800m³/d
Put into operation: February 2023
48pcs/set operating parameters:
Inlet/permeate flow: 21/15m³/h
Film inlet pressure: 43.5-46.3 bar
Inlet/Production: 23200/570μs/cm
Water quality type: coking integrated wastewater
Membrane model: SP-STRO3-8042 (75bar)
Quantity: 48 pcs
Capacity: 500m³/d
Put into operation: August 2022
Running parameters:
Permeate flow: 10m³/h
Inlet pressure: 40-45 bar
Inlet/Produced Water Conductance: 16000/500μs/cm
