Water Quality Type: Mine Water
Membrane model: TG-UP200-8830
Quantity: 53 pcs
Capacity: 3000m³/d
Put into operation: August 2024
Running parameters:
Permeate flow: 80-150m³/h
Film inlet pressure: 4.8 bar
Inlet water quality: produced water from the secondary sedimentation tank
Features: The water quality fluctuates greatly, and the polymer pollution is serious
Water quality type: kitchen biogas slurry mixture
Membrane model: TG-UF100-8830
Quantity: 14 pcs
Capacity: 500m³/d
Put into operation: December 2021
Single-group tubular membrane operating parameters:
Inlet pressure: 4.6 bar
Circulating flow: 230m³/h
Permeate flow: 13.8m³/h
Operating temperature: 33.5°C
Water quality type: incineration site leachate
Membrane model: TG-UF100-8830
Quantity: 15 pcs
Capacity: 500m³/d
Put into operation: December 2023
Biochemistry has collapsed, and the membrane is seriously blocked.
After that, the recovery of cleaning is poor
Water quality type: incineration site leachate
Membrane model: TG-UF100-8830
Quantity: 10 pcs
Capacity: 350m³/d
Put into operation: July 2023
Single-group tubular membrane operating parameters:
Film inlet pressure: 4.1 bar
Circulating flow: 274m³/h
Permeate flow: 8-13.5m³/h
Operating temperature: 35°C
COD: 1000-1600mg/L
水质类型：填埋场渗滤液
Membrane model: TG-UF100-8830
Quantity: 5 pcs
Capacity: 200m³/d
Put into operation: October 2021
Single-group tubular membrane operating parameters:
Inlet pressure: 6 bar
Circulating flow: 243m³/h
Permeate flow: 11-15m³/h
Operating temperature: 33-34°C
COD: 1600-1700mg/L
